Microwave Frequency Sweep Level Switch Quality Grade RF Admittance Microwave Intelligent Level Switch

Product description:
INQUIRY

Products Description

The sensor inductive probe, metal shell and internal electronic unit form a high-frequency resonance circuit, and a high-frequency
electric field is generated near the inductive probe. When the induction probe is covered by the medium or the dielectric constant
of the medium changes, the resonant frequency will change greatly. The internal electronic unit compares the current resonant
frequency with the user-set threshold, and the sensor turns on or off the alarm signal.

item	value
Model Number	RSTMW
Type	Liquid Level Sensor
Brand Name	RSTONE
Usage	Solid, liquid and slurry detection switch
Theory	sweep frequency
Output	npn/pnp
Description	Microwave level switch
Measurement hysteresis	±1mm
Medium characteristics	DC≥1.5
Response time	0.2s
Damping time	0~5S (can be set)
Repeatability	±1mm
Working temperature	-40~115℃ (standard type)
Process pressure	-0.1~10MPA
Wetted Materials	PEEK 304 or 316L
Wetted Surface Roughness	Ra< 0.8μm
Protection class	IP67
