Pressure gauge
Pressure gauge
- Product description: The pressure gauge shows the pressure through the elastic deformation of the sensitive elements (bourdon tube, bellows and bellows) in the gauge, and then the pressure deformation is conducted to the
I.Product description
The pressure gauge shows the pressure through the elastic deformation of the sensitive elements (bourdon tube, bellows and bellows) in the gauge, and then the pressure deformation is conducted to the pointer by the conversion mechanism of the movement in the gauge, causing the pointer to rotate to show the pressure.
II.Pressure gauge product selection guide
|
RST- |
Pressure gauge |
||||||
|
|
Code |
Connection type |
|||||
|
|
A |
Thread: M10X1、M14X1.5、M20X1.5、G1/8、G1/4、1/4NPT、 G3/8、G1/2 etc |
|||||
|
|
B |
Diaphragm threaded connection：Diaphragm type, Capillary long tail type |
|||||
|
|
C |
High temperature radiator type：Hole radiator、Slot radiator |
|||||
|
|
D |
Flange：DN15、DN 20、DN25、DN40、DN50、DN80 etc |
|||||
|
|
|
Code |
Installation |
||||
|
|
|
01A |
Radial without edges：Y-口口口 |
||||
|
|
|
01B |
Radial band back edges：Y-口口口T |
||||
|
|
|
01C |
Radial band front edges: Y-口口口Q |
||||
|
|
|
02A |
Axial without edges： Y-口口口Z |
||||
|
|
|
02B |
Axial with edges：Y-口口口ZT |
||||
|
|
|
02C |
Axial clamp connection: Y-口口口K |
||||
|
|
|
|
|
Code |
|
||
|
|
|
|
|
1 |
Shockproof: represents model N |
||
|
|
|
|
|
2 |
Anticorrosive type: represents model F |
||
|
|
|
|
|
3 |
Temperature resistant type: represents model W |
||
|
|
|
|
|
4 |
Control type |
|
|
|
|
|
|
|
|
A |
Electrical contact type： represents model YX |
|
|
|
|
|
|
|
B |
Transmission signal type,：representing model YTZ |
|
|
|
|
|
|
|
Pressure range |
|
|
|
|
|
|
|
|
A |
Positive pressure |
|
|
|
|
|
|
|
B |
Vacuum pressure |
|
|
|
|
|
|
|
C |
Micropressure |
|
|
|
|
|
|
|
|
Accuracy |
|
|
|
|
|
|
|
|
A |
0.25 |
|
|
|
|
|
|
|
B |
0.4 |
|
|
|
|
|
|
|
C |
Working level: 1, 1.6 and 2.5 |
|
|
|
|
|
|
|
|
Customized |
|
|
|
|
|
|
|
|
|
